技術(shù)參數(shù) / PARAMETERS
|
機型 Machine type |
馬達(dá) Motor power (kw) |
輸送能力 Conveying capacity (kg/hr) |
輸送高度 Conveying height (m) |
料鬥容量 Hopper capacity (L) |
吸料管徑 Suction pipe diameter (mm) |
外形尺寸 L×W×H Extemal size (mm) |
凈重 Net weight (kg) |
| XTL-1.5HP-F | 1.1 | 42 | 4 | 7.5 | 38 | 550×450×1150 | 46 |
| XTL-2HP-F | 1.5 | 550 | 4 | 7.5 | 38 | 550×450×1150 | 46 |
| XTL-3HP-F | 2.2 | 720 | 6 | 12 | 51 | 600×450×1200 | 75 |
| XTL-4HP-F | 3 | 850 | 6 | 12 | 51 | 600×450×1200 | 78 |
| XTL-5HP-F | 3.8 | 1050 | 6 | 12 | 51 | 600×450×1200 | 85 |
| XTL-7.5HP-F | 5.5 | 1250 | 8 | 50 | 63 | 1105×850×1870 | 156 |
| XTL-10HP-F | 7.5 | 1650 | 8 | 50 | 63 | 1105×850×1870 | 185 |
